280mm Width Semi-auto Die Cutting Machine for Polymer Pouch Cell Electrode Making

Name: 280mm Width Semi-auto Die Cutting Machine for Polymer Pouch Cell Electrode Making
Brand: Shenzhen TICO Technology Co.,Ltd.
SKU: STC-BMQ-SM280
Price: 4,000.00 USD
Availability: InStock

Brand Name:	TICO
Model Number:	STC-BMQ-SM280
MOQ:	1 set
Price:	Negotiable
Delivery Time:	7~12 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shen Zhen

Product Name:

Semi-auto Die Cutting Machine

Application:

For Soft Pack Battery Electrode Making

Cutting Die Size:

Max L280 * W180mm, Customizable

Air Cylinder:

3 Ton

Air Pressure:

0.5~0.7Mpa

Material Feeding:

Manual

Speed:

800~2000pcs/h

Packaging Details:

Export wooden packing

Supply Ability:

60 sets per month

Highlight:

Manual Pouch Cell Lab Equipment

170kg Pouch Cell Lab Equipment

Semi Auto Electrode Die Cutting Machine

Product Description

Semi-auto Die Cutting Equipment for Pouch Cell Electrode Making

Brief Introduction

STC-BMQ-SM280 semi-auto electrode die cutter is a necessary equipment for pouch cell electrode preparation. It is used for pouch cell electrode cutting to produce specific shapes of cathode and anode with current collector tab. Dual start buttons to ensure safety operation to avoid hands injured. The cutting without burr and high accuracy.

Features

● Different size of cutting die can be optional and easy to replace.

● The cutting no burr, no coated material drop.

● 2 Start buttons, the die can only go down only when pressing the 2 buttons at the same time. The unique design to avoid hands get injured.

● It is designed with counter, the operator can know the cutting numbers easily.

● It is semi-auto, high cutting speed.

● Long lifetime for the cutting die, >30000 times.

Technical Parameter

Model	STC-BMQ-SM280
Cutting die size	Max L280 * W180mm, customized size is available
Cuting accuracy	±0.1mm
Air cylinder	3T
Air pressure	0.5~0.7Mpa
Material feeding	Manual
Speed	800~2000pcs/h
Dimension	L550 * W455 * H900mm
Weight	155kg

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R& D department.

2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
