Dry Electrode Continuous Roll Press & Film Lamination Machine

Dry Electrode Continuous Roll Press & Film Lamination Machine

Brief Introduction

This equipment is designed for precision rolling of non-ferrous materials such as dry electrode compositions under certain temperature conditions. It features a variable steering speed ratio servo-driven system and adjustable rolling thickness, integrated with automated winding and unwinding mechanisms for continuous production.

Key Features

● The device is a multifunctional combination that can perform film formation and film lamination.

● It utilized servo motor with precision control, can be asynchronous rotation and speed arbitrarily adjustable 0 ~ 1 rps.

● Equipped with winding and unwinding correction device to realize continuously production, the steel conveyor belt to assist the stable material feeding.

● Roller internal heating to ensure the heating uniform and precise temperature control. The temperature controller features independently adjustable temperature control with a digital display.

● The roller has high hardness, and the surface is plated with hard chromium.

● Adopt stepping motor automatic to adjust the gap, with good self-locking and high adjustment accuracy.

● Equipped with a cutting mechanism to cut the material edge smoothly after film formation.

● Small size, easy to operate, flexible and fast to use.

● PLC screen control, automatic operation.

Technical Parameter

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.

3. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
