products details

Home Products

Vacuum Pump

Brand Name:	TICO
Model Number:	STC-P-VSV-20
MOQ:	1 set
Price:	Negotiable
Delivery Time:	5~8 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shen Zhen

Packaging Details:

Standard export wooden packing

Supply Ability:

100 sets per month

Highlight:

0.75Kw Lab Vacuum Pump

IP54 Lab Vacuum Pump

65db Lab Vacuum Equipment

Product Description

Vacuum Pump

Brief Introduction

This vacuum pump is an oil sealed single-stage rotary vane pump, can be used to pump inactive gas within the scope of low vacuum and a small amount of non-condensable gas, Special suitable for packaging machinery, analytical instrument, laboratory and etc. This machine owns the reasonable structure design, adopting the oil circulating air-cooled structure. High quality, high displacement speed, excellent ultimate vacuum, low noise, no oil spray, no oil leak and easy to maintenance.

Key Features

● High quality, run without failure for extended period of time.

● No oil spray, no oil leak.

● High displacement speed, excellent ultimate vacuum, low noise.

● Reasonable structure design, easy to maintenance.

Technical Parameters

Model	STC-P-VSV-20
Working rating	0.75KW
Power supply	Single/3-ph
Motor speed (50/60Hz)	3000rpm
Oil capacity	0.5L
Ambient temperature	10~40℃
Protection class	IP54
Intake and Exhaust DN	1/2″ 3/4″
Noise (Lw)	≤65dB
Allowing water vapor (Gas ballast I)	15 mbar
Ultimate pressure with gas ballast I	0.5 mbar
Pumping speed (50Hz)	20 m3/h
Dimension	L317 * W249 * H219mm
Weight	19.5kg

Warranty

1 year warranty with lifetime support.
