Heating Electrode Battery Calendering Equipment AC110V For Lab Battery Research

I'm Online Chat Now

Heating Electrode Battery Calendering Equipment AC110V For Lab Battery Research

Heating Electrode Battery Calendering Equipment AC110V For Lab Battery Research
Heating Electrode Battery Calendering Equipment AC110V For Lab Battery Research

Large Image :  Heating Electrode Battery Calendering Equipment AC110V For Lab Battery Research

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-JS100L
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wood Packing
Delivery Time: 20~25 working days
Payment Terms: T/T
Supply Ability: 20 sets per month

Heating Electrode Battery Calendering Equipment AC110V For Lab Battery Research

Description
Working Voltage: AC110V Roller Width: Dia 100 X W100mm (Other Width Can Be Optional )
Roller Hardness: >HRC62 Pressing Thickness: 0~2mm Adjustable
Feeding Speed: Max 10mm/s Adjustable Weight: 60kg
High Light:

Heating Battery Calendering Equipment

,

Lab Battery Calendering Equipment

,

AC110V Electrode Calendering Equipment

Battery Electrode Calendering Equipment with Heating for Lab Battery Research



Brief Introduction



STC-JS100L is a compact electric hot battery electrode calendering equipment,whose max temp can reach 120℃ adjustable with digital display.  The standard roller is 100mm width, others width roller is optional.



Features



● High roller hardness HRC62, surface plated by chrome treatment.

● Heating temperature max up to 120℃, digital display by thermostat.

● Safety protection cover is designed to prevent hand injured from high temperature.

● Pressing thickness can be adjusted.

● Rolling speed can be adjusted by speed controller.

● Forward & backward are available.



Technical Parameters



 Model

 STC-JS100L

 Working voltage

 AC110

 Roller

 Dia.100 x W100mm (other width can be optional )

 Roller hardness

 >HRC62

 Pressing thickness

 0~2mm adjustable

 Feeding speed

 Max 10mm/s adjustable

 Heating temperature

 Room temperature to 120℃ adjustable, digital display

 Power

 720W

 Dimension

 L380 * W280 * H366mm

 Weight

 57kg



Warranty



1 year's warranty with lifetime support.



FAQ



1. Are you a manufacturer ?



A: Yes, our factory is located in Shenzhen, China,
We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R&D department.



2. Do you accept customized product ?

A : Yes. Most of our products can be customzied to meet different requirements.



3. Will you provide test video before dispatch?

A : Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service ?

A : Yes, we can dispatch professional engineer for on-site installation service.
