300mm Pouch Cell Final Vacuum Sealing Machine With Auto Piercing

I'm Online Chat Now

300mm Pouch Cell Final Vacuum Sealing Machine With Auto Piercing

300mm Pouch Cell Final Vacuum Sealing Machine With Auto Piercing
300mm Pouch Cell Final Vacuum Sealing Machine With Auto Piercing

Large Image :  300mm Pouch Cell Final Vacuum Sealing Machine With Auto Piercing

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-BFZ300
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Nogotiable
Packaging Details: Standard export wooden box package
Delivery Time: 5~8 working days
Payment Terms: T/T
Supply Ability: 200 Set per month

300mm Pouch Cell Final Vacuum Sealing Machine With Auto Piercing

Description
Application: Pouch Cell Aluminum Laminated Case Secondly Sealing Sealing Blade Width: 300mm Width Copper Hot Sealing Blade, Digital Display For Sealing Temperature
Function: Pouch Cell Secondary Sealing, Piercing For Gas Removing Working Observing: Perspective Window
Operation: Touch Screen Controlled, Digital Display For Pressure & Vacuum Degree Feature: Sealing Time Cna Be Set
High Light:

300mm Vacuum Sealing Machine

,

Auto Piercing Vacuum Sealing Machine

,

Pouch Cell Vacuum Sealer

Pouch Cell Secondary Vacuum Hot Sealing Machine



Product Details



STC-BFZ300 vacuum sealer is used for pouch cell secondary hot sealing after electrolyte filling and battery formation. It is equipped with auto piercing needle for de-gassing the cell and do a secondary sealing under vacuum condition. 300mm Copper sealing blade, touch screen controlled with high automation.



Key Features



• It has the piercing needle, piercing function can be completed autoamtically.

• 300mm width copper sealing blade with good heating conduction.

• Sealing pressure of upper and lower sealing blade can be adjusted.

• Upper and lower sealing blade temperature can be controlled separated and settable, digital display by thermostat.

• Two start buttons for avoiding hand injured, the lid can go down only by pressing the strat bottons at the same time.

• Touch screen operation, high automation.

• Sealing time cna be set.

• Perspective window for obseving it conveniently during working.

• The lid will open automatically when finish sealing.



Technical Parameters



 Model  STC-BFZ300
 Working voltage  AC110V/220V optional
 Sealing blade length  300mm copper sealing balde, customized size is available
 Sealing balde width  5mm, customized size is available
 Upper sealing blade temp  RT~250℃ adjustable
 Lower sealing blade temp  RT~250℃ adjustable
 Sealing temp accuracy  ±2℃
 Sealing time  0~99s adjustable
 Heating sealing pressure  0.5~0.7MPa
 Power  1000W
 Dimension  L500 * W500 * H700mm
 Weight  80kg



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes, most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
