100mm Width Hot Rolling Press Machine With Winder And Unwinder

I'm Online Chat Now

100mm Width Hot Rolling Press Machine With Winder And Unwinder

100mm Width Hot Rolling Press Machine With Winder And Unwinder
100mm Width Hot Rolling Press Machine With Winder And Unwinder

Large Image :  100mm Width Hot Rolling Press Machine With Winder And Unwinder

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-JS100
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard export wooden box package
Delivery Time: 5~8 working days
Payment Terms: T/T
Supply Ability: 200 set per month

100mm Width Hot Rolling Press Machine With Winder And Unwinder

Description
Application: For Battery Electrode Calendering Customized: Electrode Winding &unwinding Device Is Optional
Pressing Thichness: Two Digital Dial Indicator For Pressing Thichness Heating Temperature: RT~150℃ Adjustable, Digital Display
Pressing Speed: 0~10mm/s Adjustable Pressing Thickness: 0.01~2mm Asjustable, (0.001mm Optional)
High Light:

100mm Hot Rolling Press Machine

,

Unwinder Hot Rolling Press Machine

,

Battery Electrode Calendering Machine

Hot Rolling Press Machine with Winding &Unwinding Device



Product Details



STC-JS100 hot rolling press machine is used for lab lithium battery electrode calendering after mental foils coating and drying process. it can equipped with winding &unwinding device for battery electrode after calendering. Two sets of digital dial indicator for pressing thickness setting easily, heating temp is adjustable for RT~150℃.



Key Features



• It is equipped with winding and unwinding device for battery electrode.

• Built-in type heating tube is adopted designing inside of the rollers for heating effect more evenly.

• Adjustable pressing thickness, digital dial indicators with memeory function when shutdown,

• Digital display speed controller, easy to control and asjust the pressing speed.

• Vertical rollers installation design for convenient feeding and pressing, forward *backward are both available.

• Heating temperature is adjustable and can be controlled separately by thermostats.



Technical Parameters



 Model  STC-JS100
 Voltage  AC110/220V optional
 Power  720W
 Roller size  Ф100 * L100mm
 Roller hardness  >HRC62
 Pressing thickness  0.01~2mm adjustable (0.001mm optional)
 Heating temp  RT~150℃ adjustable, digital display
 Pressing speed  0~10mm/s, digital display
 Dimension  L670 * W225 * H300mm
 Weight  63kg



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes, most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
