Product Details:
|
| Key Feature: | Customized Is Available | Roller Width: | 150mm Width |
|---|---|---|---|
| Dimension: | L350 * W240 * H350mm | Rolling Speed: | 0~10mm/s |
| Rolling Thickness: | 0.01~2mm Adjustable | ||
| High Light: | 150mm Width Battery Calendering Machine,240mm Battery Calendering Machine,150mm Width Roll Press Machine |
||
Roll Press 150mm Width Battery Calendering Machine Manual Calender
Customized 150mm Width Manual Roll Press Machine for Laboratory Lithium Battery R&D
Product Introduction of 150mm Width Manual Calender
STC-DLG150 manual roll press machine is a customized manual calender used inside of laboratory vacuum glovebox, it can carry out the battery electrode calendering process after coating and drying, also can be used for metal foil material roll press. 150mm width roller is our standard product, other width can be customized according to user.
Technical Parameters of 150mm Width Manual Roll Press Equipment
| Model | STC-DLG150 |
| Roller size | Φ100 * W150mm |
| Output thickness | 0.01~2mm adjustable |
| Roller hardness | >HRC62 |
| Rolling speed | 0~10mm/s |
| Dimension | L350 * W240 * H350mm |
| Weight | 60kg |
| Accessories |
Feeler *1 Digital dial indicator *2 Allen wrench *1 |
Key Features of Manual Calendering Machine
(1) Calendering thickness is adjustable with digital indicator display.
(2) Rolling press speed can be adjustable.
(3) High hardness roller, >HRC62.
(4) Forward &backward are available.
(5) Manual operate, saving power.
SHENZHEN TICO TECHNOLOGY CO., LTD
1. Total solution for Lithium-ion Battery R&D.
2. One-stop service in designing, manufacturing and marketing of battery equipment &material.
3. An integrated company of industry &trade.
FAQ
1. Are you a manufacturer?
TICO: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
TICO: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
TICO: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
TICO: Yes, we can dispatch professional engineer for on-site installation service.
