Transfer Bucket for 60L Planetary Vacuum Mixer

I'm Online Chat Now

Transfer Bucket for 60L Planetary Vacuum Mixer

Transfer Bucket for 60L Planetary Vacuum Mixer
Transfer Bucket for 60L Planetary Vacuum Mixer

Large Image :  Transfer Bucket for 60L Planetary Vacuum Mixer

Product Details:
Place of Origin: Shen Zhen
Brand Name: TICO
Model Number: STC-ZH60
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden packing
Delivery Time: 5~8 working days
Payment Terms: T/T
Supply Ability: 50 sets per month

Transfer Bucket for 60L Planetary Vacuum Mixer

Description
Mixing Power: 1.1KW Mixing Speed: 42pm Not Adjustable
Container Inner Diameter: 500mm Moving Method: Casters Moving Type
Dimension: L660*W660*H1375mm Weight: About 205Kg

Transfer Bucket for 60L Planetary Vacuum Mixer



Brief Introduction



STC-ZH60 can prevent the mixed slurry from solidifying and make slurry transfer convenient and quick. After the mixer has finished making the slurry, pull the bucket to the lifter, then cover the mixing head and combine it as a slurry transfer bucket. Complete the storage and transfer of slurry from the mixing workshop to the coating workshop.



Key Features



● Equipped with four casters, easy to move.

● Transfer bucket has a mixing head to mix the slurry all the time to prevent the slurry from solidifying.

● Can be used interchangeably with the mixing bucket on the 60L planetary vacuum mixer.

● Easy and convenient to operate.



Technical Parameters



 Model  STC-ZH60
 Power supply  AC 3×380V±5%,50Hz
 Mixing power  1.1KW
 Working frequency  50Hz
 Total design volume  88L
 Effective volume  29~60L
 Container inner diameter  500mm
 Container inner depth  450mm
 Moving method  Casters moving type
 Purpose  Interchangeable with 60L mixer bucket
 Mixing speed  42pm not adjustable
 Mixing paddle diameter  480mm
 Mixing paddle style  Inclined blade spiral
 Mixing plate material  304 stainless steel
 Dimension  L660*W660*H1375mm
 Weight  About 205Kg



Warranty:



1 year warranty with lifetime support.





FAQ



1. Are you a manufacturer?



A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
