Pneumatic Lifter for Lifting Transfer Bucket Lid

Description
Control Method: Manual Control Appearance Color: White
Dimension: L1300*W872*H1497mm Weight: About 350Kg

Pneumatic Lifter for Lifting Transfer Bucket Lid



Brief Introduction



STC-QL60 is suitable for lifting the lid of transfer bucket. The lid with the mixing head on the transfer bucket is very heavy and can be lifted very easily with a lifter.



Key Features



● Air as working medium, easy to obtain.

● Energy efficient with little energy loss.

● Simple structure, easy to maintain and repair.

● Highly safe and durable.



Technical Parameters



 Model  STC-QL60
 Air source pressure  0.5MPa~0.6MPa dry compressed air
 Air source flow  15 l/min
 Ground load  400Kg/㎡
 Lift operation panel  Manual reversing valve (with self-locking)
 Control method  Manual control
 Appearance color  White
 Lifting weight  ≤250Kg
 Dimension  L1300*W872*H1497mm (2097mm when raised)
 Weight  About 350Kg





Warranty:



1 year warranty with lifetime support.
