500℃ Round Electric Heating Die

Brand Name:	TICO
Model Number:	STC-RYM-RZ12
MOQ:	1 set
Price:	Negotiable
Delivery Time:	7~8 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Product Name:

500℃ Round Electric Heating Die

Voltage:

AC 220V±10%, 50 Hz

Power:

400W

Die Heating Range:

Rt ~ 500℃

Die Diameter:

12mm

Heating Core Outer Diameter:

43mm

Chamber Depth:

40mm

Intelligent Thermostat Dimension:

L230 * W270 * H180mm

Weight:

3.5KG

Packaging Details:

Standard export wooden packing

Supply Ability:

30 sets per month

Product Description

500℃ Round Electric Heating Die

Brief Introduction

This product is suitable for pressing and molding samples under high-temperature conditions. It features compact size, fast heating speed, and high temperature capability (up to 500°C). Equipped with a 7-inch touchscreen intelligent temperature controller, it supports multi-stage temperature control, meeting the high-temperature and high-pressure sample preparation requirements for various materials.

Technical Parameters

Model	STC-RYM-RZ12
Voltage	AC 220V±10%, 50 Hz
Heating jacket power	400W
Die heating range	Rt ~ 500℃
Die diameter	12mm
Heating core outer diameter	43mm
Heating jacket outer diameter	78mm
Chamber depth	40mm
Pressure control accuracy	0.1T (Customizable self-setting accuracy)
Holding time	No time limit, reach the set time to stop heating
Display mode	7 inch touch LCD screen (more convenient operation)
Intelligent thermostat temp control range	Rt ~ 800℃
Intelligent thermostat temp control mode	5 sections adjustable continuous, segmented temperature control
Dimension	L230 * W270 * H180mm
Weight	3.5kg

Warranty

1 year's warranty with lifetime technical support.

FAQ

1. Are you a manufacture ?

A: Yes,our factory is located in Shenzhen, China.

We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R&D department.

2. Do you accept customized product ?

A: Yes. Most of our products can be customized to meet different requirments.

3. Will you provide test video before dispatch ?

A: Yes, we take test video for every equipment before dispatchm which will display how to use it.

4. Can you offer overseas installation service ?

A: Yes, we can dispatch professional engineer for on-site installion service.
