Slot Die Roll To Roll Coating Machine With One Oven

Brand Name:	TICO
Model Number:	STC-TMJ-300
MOQ:	1 set
Price:	Negotiable
Delivery Time:	20~25 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Voltage:

3Phase AC380V, 50HZ

Power:

15KW

Roller Width:

360mm

Effective Coating Width:

≤300mm

Oven Length:

Dimension:

L1900 * W1100 * H1250mm

Weight:

1.2T

Packaging Details:

Standard export wooden packing

Supply Ability:

10 sets per month

Product Description

Slot Die Roll To Roll Coating Machine With One Oven for Lab Battery R&D

Brief Introduction

This product is a high-precision coating equipment for continuous and intermittent coating, which is convenient for surface coating process of various substrates. Especially used in the lithium ion battery industry, the equipment is designed to facilitate the use of researchers, meet the requirements of coating accuracy and consistency, and has excellent drying effect. It is an ideal choice for the research and development of lithium ion batteries, super capacitors, nickel batteries and other secondary batteries.

Key Features

● It can be switched freely to realize continuous and intermittent coating.

● Tension control substrates and electrode material belt running stability, also equipped with correction device.

● Hot air oven, blowing up and down, high quality drying effect.

● PLC control, touch screen operation, easy to use.

● Solvent recovery treatment unit is optional.

Technical Parameters

Model	STC-TMJ-300
Voltage	3Phase AC380V, 50HZ
Power	15KW
Dimension	L1900 * W1100 * H1250mm
Weight	1.2T

Equipment Function:

No.	Item	Technical Parameters	Notes
1	Application	Anode & cathode electrode coating process for lithium iron phosphate, lithium cobaltate, lithium manganate and other battery systems
2	Coating method	Continuous coating/intermittent coating/tracking coating
3	Run the substrate thickness	Aluminum foil (Al): 11 ~ 30μm Copper foil (Cu): 8 ~ 30μm
4	Guide roller design width	340 mm	Aluminum roller
5	Guaranteed coating width	≤300mm
6	Mechanical operating speed of equipment	3m/min
7	Coating speed	0.3-0.5m/min	Depending on the drying condition
8	Slurry viscosity applicable range	2000~12000 Cps
9	Single side coating thickness after drying	50-150μm
10	Min intermittent length	5mm
11	Multistage min coating length	20mm
12	Solvent characteristics	Oily solvent NMP(s.g=1.033,b.p=204℃)
12	Solvent characteristics	Aqueous solvent H2O/NMP(s.g=1.000,b.p=100℃)
13	Solid content range	Cathode S. C. 60% ± 5%
13	Solid content range	Anode S. C. 50% ± 5% (PVDF system) S. C. 50% ± 5% (SBR system)
14	Specific gravity	Anode 1.5 — 2.59/cm2 Cathode 1-1.89/cm2
15	Substrate running direction	Forward coating, substrate forward and reverse empty foil operation

Warranty

1 year's warranty with lifetime technical support.

FAQ

1. Are you a manufacture ?

A: Yes,our factory is located in Shenzhen, China.

We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R&D department.

2. Do you accept customized product ?

A: Yes. Most of our products can be customized to meet different requirments.

3. Will you provide test video before dispatch ?

A: Yes, we take test video for every equipment before dispatchm which will display how to use it.

4. Can you offer overseas installation service ?

A: Yes, we can dispatch professional engineer for on-site installion service.
