3L Lab Desktop Double Planetary Vacuum Mixer

Brand Name:	TICO
Model Number:	STC-EXJ-3LZ
MOQ:	1 set
Price:	Negotiable
Delivery Time:	15~20 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shen Zhen, China

Designed Capacity:

3 L

Effective Working Capacity:

2 L

Revolution Speed:

0-75 rpm

Buffer Tank:

1 Pcs

Viewing Port:

2 Pcs

HMI:

7-inch Touchscreen, Supports Memory Card

Packaging Details:

Standard export wooden packing

Supply Ability:

5 sets per month

Highlight:

Planetary vacuum mixer

vacuum mixing machine

Lab battery slurry mixer

Product Description

3L Desktop Lab Double Planetary Vacuum Mixer

Brief Introduction

It’s used for mixing dispersion of various common battery powder and liquid to achieve uniform battery slurry, especially for the high viscosity technological process.

Technical Parameters

Model	STC-EXJ-3LZ
Voltage	380V, 50 Hz, 3 Phase
Dimension	L880×W480×H930mm
Weight	303Kg

Part 1. Mixing Tank

Inner tank dimension	φ180 × 120 mm
Designed capacity	3 L
Effective working capacity	2 L
Inner and outer liners	Inner and outer liners are made of SUS304 stainless steel. The inner liner and bowl bottom are lathe‑machined; the inner liner is polished to 300-grit by an automatic polishing machine; the outer surface of the bowl is finished to 200-grit. The flow-deflecting plate is externally turned on a lathe for seamless fitting with the jacket plate.
Cooling water inlet/outlet	DN10, equipped with 2 sets of quick connectors.
tank bottom	equipped with a jacket and flow guide strips.
Material discharge	DN25 ball valve
Handle	Two handles are provided on the tank body

Part 2. Dispersing Shafts

Material	SUS304
Dispersing speed	0–11200 rpm
Dispersing shafts quantity	2 sets, each dispersing shaft is equipped with one φ40 mm dispersing disc.
Bearing	Imported high-speed bearings
Oil seal	Fluororubber (FKM) shaft oil seals
Linear speed	0–22 m/s
Transmission belt	The transmission belt in the planetary box is a synchronous belt

Part 3. Mixing Paddle

Planetary gearbox	SUS304, fully sealed
Revolution speed	0-75 rpm
Drive	750 W servo motor with precision planetary reducer
Twisted frame mixing paddle speed	0–250 rpm, 2 sets the mixing paddles are integrally cast precision machined by a four-axis linkage machining center, and then polished to 300-grit
Distance between mixing paddle and tank wall	3±1mm
Distance between mixing paddle	4±1mm
Distance between paddle and tank bottom	3±1mm

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

A: Yes, most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
