7L Muffle Box Type Drying Furnace For Lab Research

I'm Online Chat Now

7L Muffle Box Type Drying Furnace For Lab Research

7L Muffle Box Type Drying Furnace For Lab Research
7L Muffle Box Type Drying Furnace For Lab Research

Large Image :  7L Muffle Box Type Drying Furnace For Lab Research

Product Details:
Place of Origin: Shen Zhen
Brand Name: TICO
Model Number: STC-G07123
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden packing
Delivery Time: 8~12 working days
Payment Terms: T/T
Supply Ability: 100 sets per month

7L Muffle Box Type Drying Furnace For Lab Research

Model: STC-G07123 Power: 3Kw
Thermocouple: Type "K" Max Heating Rate: ≤15℃/min
Heating Element: OCr27A17Mo2 Volume: 7L
High Light:

Box type Drying Furnace


7L Drying Furance


Lab Muffle Furance

Muffle Furance Box-type Drying Furance for Lab Research


Product Introductions


This furnace is mainly used for carrying out the sintering, annealing and oxidation experiment for ceramic material, composite material, mental material, functional material, heating material, crystal material, etc. It is widely used for universities, research institutes, enterprise R&D centers, quality inspection units, processing industries, etc.


Key Features


• Automatic power off when open the door.

• Over-temperature protection, when the temperature exceeds the pre-set temp, it will power off and alarm automatically.

• It will automatically cut off power in case of electricity leakage.

• The temperature control system adopts artificial intelligence adjustment technology, which is owning the PID automatic control, fuzzy control, auto-tune function, and programmable for temp control.

• The furnace inside is equipped with 485 Conversion Interface, which is capable to carry out connecting with one or up to 200 furnaces by professional computer control system to realize the remote control, real-time track, data record, output report and etc.

• The furnace inside is made of Alumina ceramics by vacuum adsorption. Energy saving, heating evenly.


Technical Parameter


 Model  STC-G07123
 Voltage  AC220V
 Power  3Kw
 Chamber material  Alumina ceramic fiber
 Chamber size  L300 * W200 * H120mm
 Temperature accuracy  ±1.0℃
 Opering method  Side door design, power off whrn open the door
 Max temperature  1200℃
 Heating element  OCr27Al17Mo2
 Furnace structure  Integrartion of heating box and controlling box
 Temperature control  PID automatic control and 30 segments programmable for temperature control
 Max heating rate  ≤15℃/min
 Temperature  Type "K" thermocouple
 Volume  7L
 Dimension  L590 * W460 * H682mm
 Weight  85kg
 Remark  sintering corrosive & volatile samples are prohibited




1 year warranty with lifetime support. Man-made damage is not covered.




1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.


2. Do you accept customized product?

A: Yes, most of our products can be customized to meet different requirements.


3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.


4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
