Product Details:
|
| Model: | STC-TM300L | Coating Length: | Max300mm, Customized Size Is Acailable |
|---|---|---|---|
| Doctor Blade: | 100mm Fixed Width Is Standard | Coating Speed: | 0~100mm/s Adjustable |
| Dimension: | L500 * W310 * H200mm | Weight: | 50kg |
| High Light: | Electrode Film Coating Machine,Classic Electrode Film Coating Machine,Laboratory Battery Film Coating Machine |
||
Classic Push-button Battery Electrode Film Coating Machine for Laboratory
Brief Introduction
STC-TM300L is a compact tape casting machine with vacuum chuck, which widely used in all kinds film coating research, like ceramic films, crystal films, lithium battery electrode coating, etc.
Features
• Vacuum aluminium chuck is designed for quick suction of substrate.
• Coating stroke length is adjustable.
• Black doctor blade, easy to clean.
• Classic push-button design, stable performance.
Technical Parameter
|
Working voltage |
AC220V optional |
|
Max coating stroke length |
300mm adjustable ( customized size is available ) |
|
Doctor blade |
100mm fixed with & adjustable width, other width optional |
|
Coating thickness range |
0.01~3.5mm adjustable |
|
Vacuum chuck |
L410 * W200 * H30mm |
|
Coating speed |
0~100mm/s adjustable |
|
Dimension |
L550 * W310 * H200mm |
|
Weight |
50kg |
Warranty
1 year's warranty with lifetime technical support.
FAQ
1. Are you a manufacturer ?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R& D department.
2. Do you accept customized product ?
A : Yes, Most of our products can be customzied to meet different requirements.
3. Will you provide test video before dispatch?
A : Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service ?
A : Yes, we can dispatch professional engineer for on-site installation service.
