Product Details:
|
| Character: | PID Adjustment | Over Temp: | RT~250℃ Adjustable |
|---|---|---|---|
| Inner Chamber Temp Error: | ±4℃ (No Load In Vacuum State) | Vacuum Hodling Time: | ≥98% After 24 Hours At -0.98KPa |
| Operation: | Touch Screen Controlled | Wieight: | 960kg |
| High Light: | PID Adjustment Vacuum Drying Cabinet,18kw Vacuum Drying Cabinet,AC380V Laboratory Dry Oven |
||
Three Layers Vacuum Drying Equipment
Key Characters
• 3 layers stainless steel inner chamber with 3mm thickness, anti-resistance and durable.
• The device is equipped with universal movable casters for moving easily.
• The equipment adopts 304 stainless steel heating tube coiled inside the heating type, uniform temperature control, the device has been monitored at 80℃, 100℃, 120℃ and other temperature monitoring points to monirtor the temperature before delivery.
• The equipment is sealed with silicone rubber seals, 15mm thick tempered glass dooe, each door is designed with an observation windows.
• Side-door designed, each chamber was divided into 3 layers by two stainless brackets.
• Elasitci double glass door with overpressure protection.
• PID adjustable, small thermal inertia, good temperature control.
• Touch screen controlled, which is convenient and reliable for operation.
Technical Parameters
| Model | STC-KZK-3D |
| Voltage | AC380V, 50Hz |
| Power | 18kw |
| Over temp | RT~250℃ adjustable |
| Inner liner dimension | W660 * D900 * H330mm |
| Inner chamber temp error | ±4℃ (No load in vacuum state) |
| Protection function | Automactic power failure protection, Automatic over-temp alarm |
| Vacuum holding time | ≥98% after 24 hours at -0.98KPa |
| Vacuum degree | -0.98KPa |
| Dimension | W1500 * D1400* H1850mm |
| Wieight | 960kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
